Features
● Continuous packing motion without stopping the product
● Servo drive system ensures prerise and stable performance.
● Capable to plug-in different optional infeed system for diferent products.
● Quick change over by calling data from touch panel.
● Side seal device can reduce wastage films usage.
● Excellent perforation system allows the pin easily to change and adjust.
Technical Data
| Model | EHP-400T | EHP-400S | EHP-550T |
| Machine size(mm)* L×W×H | 6300×1825×1385 | 2855×1805×1385 | 5595×2060×1315 |
| Packing size (mm)* L×W×H | (60-1000)×(50~400)×(5~ 120) | (60-1000)×(50~400)×(5~ 120) | (60~100)×(100~ 500)×(5~120) |
| End seal bar (mm) | 500 | 500 | 630 |
| Power | 1P,220V,3.5Kw | 1P,220V,3.5Kw | 1P,220V,3.5Kw |
| Pneumatic | Max. 80 | Max. 120 | Max. 80 |
| Pneumatic | 55psi, 4Kg/sq.cm | 55psi, 4Kg/sq.cm | 55psi, 4Kg/sq.cm |
Tailor made version is available
